Sterylis BASIC-150

PROFESSIONAL ROOM STERILIZERS
  /    /  Sterylis BASIC-150

150 m3

Maximum recommended cubic capacity
rooms for UV-C disinfection

WORK MODES:

Sterylis BASIC-150
Filtration
Sterylis BASIC-150
Disinfection
UV-C

STERYLIZATOR POMIESZCZEŃ VS

UV-C disinfection
– silent mode
Sterylis BASIC-150

TECHNICAL SPECIFICATIONS:

STANDARD MODE – UV-C DISINFECTION

Recommended cubic capacity of the disinfected room (assuming 24 h/day operation)150 m³

The maximum dose of UV-C radiation

120 J/m2

Fan performance UV-C disinfection mode

300 m3/h

Noise level – disinfection mode UV-C

52 dB(A)

SILENT MODE – UV-C DISINFECTION

The maximum dose of UV-C radiation

150 J/m2

Fan performance UV-C disinfection mode (silent)

340 m3/h

Noise level – disinfection mode UV-C (silent)

50 dB(A)

FILTRATION MODE

Fun capacity in filtering mode

300 m3/h

Noise level – filtering mode

52 dB(A)

UV lamp

YES

Type lamps UV

UV-C sterilization C λ= 253,7 nm

Electrical power of UV lamps

100 W

Durability of UV lamps

9000 h

Power of the UV light source

36 W

Air filtering

2-stage

Fan type

radial

Fan engine

enclosed

Type

flowtype

Power supply

230 V (AC), 50 Hz

Rated current

0,8 A

Rated power

180 W

Power cable length

3 m / 10 m*

Dimensions (H x W x D)

700 x 360 x 275

Net weight

16 kg

Type of housing

metal, powder-coated

Transport wheels/handles

handle

Additional functions

detachable power cord

* – option available after consultation with the sales department
