400 m3
Maximum recommended cubic capacity
rooms for UV-C disinfection
WORK MODES:

Filtration

Disinfection
UV-C
UV-C disinfection
– silent mode

TECHNICAL SPECIFICATIONS:
STANDARD MODE – UV-C DISINFECTION | |
Recommended cubic capacity of the disinfected room (assuming 24 h/day operation) | 400 m³ |
The maximum dose of UV-C radiation | 388 J/m2 |
Fan performance UV-C disinfection mode | 550 m3/h |
Noise level – disinfection mode UV-C | 56 dB(A) |
SILENT MODE – UV-C DISINFECTION | |
The maximum dose of UV-C radiation | 521 J/m2 |
Fan performance UV-C disinfection mode (silent) | 320 m3/h |
Noise level – disinfection mode UV-C (silent) | 52 dB(A) |
FILTRATION MODE | |
Fun capacity in filtering mode | 550 m3/h |
Noise level – filtering mode | 56 dB(A) |
UV lamp | YES |
Type lamps UV | UV-C sterilization C λ= 253,7 nm |
Electrical power of UV lamps | 330 W |
Durability of UV lamps | 9000 h |
Power of the UV light source | 118 W |
Air filtering | 2-stage |
Fan type | radial |
Fan engine | enclosed |
Type | flowtype |
Power supply | 230 V (AC), 50 Hz |
Rated current | 1,9 A |
Rated power | 440 W |
Power cable length | 3 m / 10 m* |
Dimensions (H x W x D) | 1410 x 700 x 735 |
Net weight | 32 kg |
Type of housing | metal, powder-coated |
Transport wheels/handles | handle |
Additional functions | detachable power cord |
* – option available after consultation with the sales department
